Matrikon Data Broker

Facilitate data integration and synchronization between different systems.
Manual Datasheet

Matrikon Data Broker (MDB) establishes and manages data access to your 3rd party control automation data sources regardless if the connections are across the shop floor, throughout your enterprise, or to the cloud.

MDB now supports user-controlled OPC UA Data Modeling and Data Mapping. Using an easy-to-use graphical user interface, users can drag and drop OPC UA Companion Specification (CS) files into MDB to import new data types. Once the new types are imported, users can instantiate the new types and map data from federated data sources so the rest of the organization can work directly with the data model context instead of the underlying data sources.

MDB uses the latest open standard data connectivity technologies like OPC UA and MQTT to solve complex shopfloor connectivity challenges and overcome IT/OT gaps “under the hood” so companies can focus on putting their shopfloor data to work instead of wasting time and resources trying to access it.

Architecture Overview

Use Matrikon Data Broker on the operating system of your choice. Run it as either
a local application or as a Linux container.



Matrikon Data Broker defines a software category called Data Technology (DT) because it eliminates IT/OT gaps and other complex data connectivity challenges "under the hood." The use of DT enables the creation of a Unified OT data Layer (UODL), a single, scalable, and holistic data connectivity experience enterprise-wide. MDB enables users across the enterprise to focus on extracting value from shopfloor data instead of trying to access

Connect seamlessly with Siemens PLCs using the Matrikon OPC Server

Whether you're using SIMATIC Ti5, S5, or S7 series, our server ensures reliable communication across various protocols and media options. Simplify your PLC integration today!
Contact Us

Take charge of how you connect to, represent, and share your shopfloor data with Matrikon Data Broker (MDB), the one-stop solution for the setup and management of a Unified OT data Layer (UODL) for secure data connectivity throughout your OT networks, enterprise IT networks, and the cloud.

Supported Standards

OPC UA DA (OPC UA Data Access)
OPC Classic DA (Data Access) via Matrikon OPC UA Tunneller
OPC UA Companion Specifications
MQTT v1.3 (via the MQTT Publisher extension)
Publish functionality
OPC UA PubSub conformant JSON encoding for seamless support of
underlying OPC UA Companion Specification-based data (i.e., standardized Information Models)

Hardware Requirements

The following are the minimum PC hardware requirements:

CPU 4-cores
8GB RAM
80 GB Hard Drive
TCP/IP connectivity

Supported OS

Windows 10, 11
Windows Server 2012, 2016, 2019, 2022
Linux Ubuntu 18.04, 20.04, 22.04
Linux CentOS 8.0
Linux Red Hat 8.0, 9.x (RHEL)

Key Benefits & Advantages

 Data Context Enhancement and Data Sharing
 Secure and Reliable Cloud Connectivity
 Enterprise IT-Grade Administration
 Comprehensive Shopfloor Data Connectivity Options

3rd Party OEM Ready

Matrikon offers control automation suppliers and solution providers the option to OEM its MDB Data Technology so they can use it as an OT data connectivity and interoperability foundation in their offerings. By standardizing on MDB, vendors can focus their time and development resources on their core areas of expertise while building on a world-class, open-standards-based, enterprise-ready OT data system.
