Temperature/Humidity Sensor (Probe)

The X-DTHS-P is a temperature and humidity sensor probe which is used in conjunction with many of the 400-Series, X-600M, and WebRelay-Wireless products.

The X-DTHS-P is a temperature/humidity sensor for use in a broad range of industrial applications

Use the probe to monitor both temperature and humidity in indoor/outdoor conditions. The X-DTHS-P is easy to use and comes with both wall and thruwall (for HVAC duct) mount brackets. A built in sintered bronze filter protects the sensor from dust and insects.

Temperature Range: -40°C to 80°C (-40°F to 180°F)
Temperature Accuracy: ±0.4°C (typ 0°C to 80°C)
Lead Length: 10ft (3.04m)
Type: Digital 1-Wire (Maxim Semiconductor DS18B20)

Use the probe to monitor both temperature and humidity in indoor/outdoor conditions, coolers, warehouses, factories and many more applications. The X-DTHS-P is easy to use and comes with both wall and thruwall mount brackets. A built in sintered bronze filter protects the sensor from dust and insects.

One or multiple sensors can be attached to the 1-Wire Bus and its cables can be extended up to 600 feet (approximately 182 Meters) from the module without any loss of measurement accuracy



The X-DTHS-P comes with two mounting options:

Mounting Clip – For ease of mounting against a surface.
Thru-Wall Mounting Bracket – For HVAC duct monitoring. The bracket has a foam gasket to seal the access hole

The sensor can be installed outdoors but must be protected from the elements. Install the sensor in a protected location away from rain or direct sunlight.

No additional software, or power supply required. Simply connect and set up on any of our compatible products

Temperature Sensor Wiring

The sensor has three wires which are connected to a compatible ControlByWeb device.
The cable can be extended with additional wire if needed (600ft max).



Keep your environment in check with the X-DTHS-P

Monitor temperature and humidity with precision—indoors or outdoors. Order now and ensure reliable performance with our easy-to-install, dust-protected sensor!

The X-DTHS-P is a new temperature and humidity sensor probe which is used in conjunction with many of the 400-Series, X-600M, and WebRelay-Wireless products. Temperature and humidity are accurately measured, digitized, and sent to the ControlByWeb module over a serial 1-Wire Bus.

Features

Temperature Range: -40°C to 80°C (-40°F to 180°F)
Temperature Accuracy: ±0.4°C (typ 0°C to 80°C)
Humidity Range: 0-100% RH(Not suitable for environments with reoccurring or prolonged condensation)
Humidity Accuracy: ±2%
Type: Digital 1-Wire (Maxim Semiconductor DS18B20)
Lead Length: 10ft (3.04m)
Probe Length: 3.92in (99.6mm)

Compatible Products

X-400
X-400C
X-404
X-404C
X-405
X-406
X-410
X-420
X-600M
WebRelay Wireless

Capabilities

Sensor measures both temperature and humidity
Includes wall mounting clip and thru-wall mount bracket
10-foot thermoplastic rubber cable
Sintered bronze pre-filter protects the sensor from dust and insects
Sensor element has a PTFE cover to protect the sensor under harsh environmental conditions
➢ Fully calibrated, linearized, and temperature compensated
Digital “1-Wire®” interface
Easy to use
Sensor cable can be extended

Installation Instructions

Mount the X-DTHS-P sensor using either the wall mount clip or the thru-wall bracket. The thru-wall bracket is normally used to install the sensor in a HVAC duct and has a foam gasket to seal the access hole. The sensor can be installed outdoors but must be protected from the elements. Install the sensor in a protected location away from rain or direct sunlight. The sensor has 3-wires which are connected to a compatible ControlByWeb device. The cable can be extended with additional wire if needed.
