X-410™ | Edge Programmable Controller

Engineering & Marketing International

Versatile, Easy Monitoring & Control

  • X-410W-I,X-410-I,X-410-E

Simplify any industrial application with the X-410™—no code necessary. Automation is easy with its web-based interface, intuitive drop-down menus, and logic editor. Integrate different devices, sensors, and protocols to create a cohesive system that responds intelligently to changing conditions. Control lights, sensors, and more with built-in I/O and expandable modules.

  • 4 Relays
  • 4 Digital Inputs
  • Up to 16 Temp Sensors

WiFi is Now Available. Note that X-410W models include WiFi capability which allows for more flexibility and cost savings for your application.

The X-410 is one of our most versatile PLCs. It can monitor up to 4 contacts and control up to 4 relays. This combination has proven to be very popular and extraordinarily flexible.

X-410 Features

  • Email Notifications
  • Real-Time Clock with NTP server synchronization
  • No-Code Logic Builder
  • Peer-to-Peer Communication
  • Data Logging
  • 400 Series Platform

X-410 Applications

  • Door & Access Control
  • Network Device Rebooting
  • Alarm Panel Monitoring
  • Motor Control

X-410W: WiFi-Enabled Remote Monitoring

When a hardwired Ethernet connection isn’t practical, WiFi connectivity allows you to easily set up, monitor, and control your I/O module wirelessly. The built-in WiFi capability of the X-410W allows you to create logic, monitor inputs, and trigger relays through a standard web browser and WiFi network.

The Benefits of WiFi PLCs

  • Flexibility: WiFi-enabled PLCs are often used when a hardwired Ethernet connection isn’t feasible.
  • Cost: With WiFi, integrators can avoid the expense of burying a line, channeling Ethernet cables, and installing other physical components.
  • Ease of Installation: Our WiFi-enabled PLCs can be assigned network credentials through the built-in interface.

Built-In No-Code Programming

The X-410 comes with a built-in web interface, making programming a breeze. No more complicated ladder diagrams – just simple “if this then that” logic programmed with drop-down menus.

Easily create tasks based on time, input or outputs’ status, or device responsiveness. Create up to three actions for each task providing you with the ultimate control and monitoring solution for your application!

Create up to 50 Scheduled Tasks, 50 Conditional Tasks, 16 Auto Reboot Tasks, and 20 Override Schedules.

Specifications

Power Requirements

  • Voltage:
    • X-410-I: 9-28 VDC
      X-410-E: POE and/or 9-28VDC
      X-410W-I: 9-28VDC
  • Max Current: 240mA

Relay Contacts

  • Number of Relays: 4
  • Max Voltage: 28VAC, 24VDC
  • Max Current: 1A
  • Contact Type: SPST (Form A) All Relays have a shared common
  • Load Type: General Purpose
  • Contact Resistance: 1 milliohm max
  • Contact Material: AgNi
  • Electrical Life: 100K operations (Min)
  • Mechanical Life: 5M cycles (Min)
  • Environmental Rating: Over voltage Category II, Pollution Degree 2
  • Relay Modes: ON/OFF or Pulsed
  • Pulse Timer Duration: 0.1 to 86,400 Seconds (1-day)

Digital Inputs

  • Number of Inputs: 4
  • Type: Optically-Isolated
  • Voltage Range: 4-26VDC
  • Current: 950uA @ 4V, 8.5mA @ 26V
  • Minimum Hold Time: 20ms
  • Input Functions: Monitor State, Control Relays, Control Remote Relays, Scalable Counter, On Timer, Total On Timer, Frequency
  • Maximum Count: 24-bit
  • Max Count Rate: 200Hz Max (Dependent on Configuration)
  • Edge Trigger: Rising, Falling or Both

Temperature Sensors

  • Maximum Number of Sensors: 16
  • Type: Digital 1-Wire (Maxim Semiconductor DS18B20)
  • Temperature Range: -67°F to 257°F (-55°C to +125°C)
  • Accuracy: ±0.5°C (from -10°C to +85°C)
  • Sensor Functions: Monitor Temperature, Log Temperature, Email Alerts, SNMP Traps
  • Humidity Type: ControlByWeb Model X-DTHS-P sensor
  • Humidity Range: 0-100% RH
  • Accuracy: ±2%
  • Max Cable Length: 600 feet (180m) maximum combined cable length

Real-Time Clock

  • Manual or NTP(Network Time Protocol) setup
  • NTP Sync Period: Once, Daily, Weekly, On Powerup
  • Auto Daylight Savings Adjustment
  • Battery (capacitor) Power Backup

Capacitor Power Backup

  • Backup Functions: Retain Real-Time Clock, 1 Register, 2 Counters, 4 Relay States
  • Backup Duration: 24 hours

Network

  • Type: 10/100 Base-T Ethernet Port
  • Setup: Static or DHCP IP address configuration
  • Wireless: WiFi Communication (X-410W model only)

Connectors

  • Power, Outputs, and Inputs: 14-Position, 3.81mm, Removable
  • Network: 8-pin RJ-45

LED Indicators

  • Number of LEDs: 11Power on
    • Relay coil energized 1-4
    • Digital Inputs 1-4
    • Network linked
    • Network activity

Wireless

  • Network Standards: IEEE 802.11 b/g/n
  • Frequency Band: 2.412 – 2.462 GHz
  • Wi-Fi Security Standards: WPA2, WPA3
  • Network Settings: DHCP or Static

Physical

  • Operating Temperature: -40°F to 150°F (-40°C to 65.5°C)
  • Size:
    • 1.41in (35.7mm) wide
    • 3.88in (98.5mm) tall
    • 3.1in (78mm) deep (not including connector)
  • Weight: 5 oz (142 grams)
  • Enclosure Material: Lexan 940 Polycarbonate Plastic
  • Enclosure Flame Rating: UL94 V0

Protocols

  • HTTP, HTTPS, SSL, XML, Modbus TCP/IP, SNMP, SMTP, Remote Services

Logging

  • Log File Size: 512K (up to 8,448 logs)
  • Storage: Nonvolatile Flash
  • Buffer Architecture: Circular Buffer

Advanced Features

  • Task Builder
  • BASIC interpreter
  • Remote services

Password Settings

  • Password Length: 6-18 Characters

Electromagnetic Compliance

  • IEC CISPR 22, CISPR 24
  • EU EN55024, EN55022
  • X-410-I: FCC 47CFR15 (Class B)
  • X-410-E: FCC 47CFR15 (Class A)

Product Safety Compliance

  • IEC 61010-1
