Flexible & Remote Relay Control
- X-WR-1R12-1I-I,X-WR-1R12-1I-E
Harness I/O through the internet with the original WebRelay™. It is an electromechanical relay featuring a built-in web server and optically isolated input that can be used to monitor dry contacts or control industrial equipment.
- 1 Relay
- 1 Digital Input
The WebRelay serves as the standard for controlling and monitoring devices from the comfort of your web browser. This simple network-controlled PLC is powerful and flexible—ideal in applications like pump and motor control, security lock systems, remote reboot, and lighting control.
WebRelay Features
- Simple Web Dashboard
- Password Protected
- Automatic Reboot
- Remote Relay Control
WebRelay Applications
- Pump & Motor Control
- Lighting Control
- Network Device Rebooting
- Security Lock Systems
Specifications
Models
- X-WR-1R12-1I-I
- X-WR-1R12-1I-E
Power Requirements
- Voltage:
-
- X-WR-1R12-1I-I: 9-28VDC
- X-WR-1R12-1I-E: POE and/or 9-28VDC
- Max Current: 460mA Max
Relay Contacts
- Number of Relays: 1
- Max Voltage: 240VAC, 30VDC
- Max Current: 12A
- Contact Type: SPDT (Form C)
- Load Type: General Purpose
- Contact Resistance: < 30 milliohms initial
- Contact Material: AgSnO2
- Electrical Life: 100K cycles (Typical)
- Mechanical Life: 10M cycles (Typical)
- Environmental Rating: Over voltage Category II, Pollution Degree 2
- Relay Modes: ON/OFF or Pulsed
- Pulse Timer Duration: 0.1 to 86,400 Seconds (1-day)
Digital Inputs
- Number of Inputs: 1
- Type: Optically-Isolated
- Voltage Range: 4-26 VDC
- Current: 950uA @ 4V, 8.5mA @ 26V
- Minimum Hold Time: 62.5mS
- Input Isolation: 1500V
- Input Functions: Monitor, Local Relay Control, Remote Relay Control
Network
- Type: 10/100 Base-T Ethernet Port
Connectors
- Relay: 3-Position Removable
- Power/Input: 5-Position Removable
- Network: 8-pin RJ-45
LED Indicators
- Number of LEDs:
- 4Digital input voltage applied
- Relay coil energized
- Network linked
- Network activity
Physical
- Operating Temperature: -40°F to 135°F (-40°C to 57°C)
- Storage Temperature: -40°F to 185°F (-40°C to 85°C)
- Humidity: 5% to 95% non condensing
- Size:
- 1.41in (35.7mm) wide
- 3.88in (98.5mm) tall
- 3.1in (78mm) deep (not including connector)
- Weight: 5 oz (142 grams)
- Enclosure Material: Lexan 940 Polycarbonate Plastic
- Enclosure Flame Rating: UL94 V0
Protocols
- HTTP, XML, Modbus TCP/IP
Password Settings
- Password protection on setup page: Yes
- Password protection on control page: Optional
- Password Encoding: Base 64
- Password Length: 10 Characters
Electromagnetic Compliance
- IEC CISPR 22, CISPR 24
- EU EN55024, EN55022
- FCC 47CFR15 (-I Models class B, -E POE Model Class A)
Product Safety Compliance
- UL 61010-1 (Electrical Equipment for Measurement, Control, and Laboratory Use) – Models: X-WR-1R12-1I-I and X-WR-1R12-1I-E
