MPX Float Sensor

Monitor liquid levels with a float level sensor and a ControlByWeb® module. Receive text/email alerts when a user-specified level is reached. Log and graph a tank’s level data over time.
Datasheet

MPX Float Sensor

Monitor liquid levels with a float level sensor and a ControlByWeb® module. Receive text/email alerts when a user-specified level is reached. Log and graph a tank’s level data over time.

Modbus RS-485
4-20mA, 2-Wire

Float Sensor – Liquid Level Switch

Monitor liquid levels with a float level sensor and a ControlByWeb® module. Receive text/email alerts when a user-specified level is reached. Log and graph a tank’s level data over time.

How do Float Sensors Work

Magneto strictive liquid level sensors consist of a float that moves up and down a stem, or rod. The float contains a permanent magnet, and the stem houses a wire waveguide that creates a magnetic field, making it possible to detect the floats position on the stem. An electrical pulse travels down the waveguide, magnetizing it. When the pulse meets the magnetic field from the float, a vibration, also called a strain pulse, travels back to the sensor housing.
The Float sensor or liquid level switch then measures the difference in time between the initial pulse, and the strain pulse, giving it an accurate and continuous reading of the tank’s current level.

Liquid Types
Float Level Sensors work well with clean and dirty liquids, as they are customizable for almost any application

Recommended Installation

Top of Tank
Carefully lower the MPX Float Sensor into the tank, then secure the sensor to the tank. If the floats don’t fit through the mounting hole, remove the floats and connect the floats from the inside of the tank after the stem has been lowered through the mounting hole.



Remote Monitoring



Remote Control & Monitoring

Each float sensor can be connected to a ControlByWeb module to remotely monitor liquid levels in real-time using a standard web browser or mobile device. Liquid levels can be presented to the user as a simple liquid height measurement, or the module can be configured to calculate the volume of liquid used or the volume remaining in the tank and present that to the user.



In addition to simple remote monitoring, ControlByWeb modules are fully programmable and provide custom control capabilities as well.
For example, you can connect a pump to a relay on a ControlByWeb module and remotely run the pump manually, or configure the pump to automatically run if the level gets too low.

Level Monitoring in Hazardous Environments

Warning: Use of these products to monitor tank levels of potentially explosive liquids or substances (such as gasoline), requires strict adherence to local safety laws and regulations. ControlByWeb modules (such as the X-404, X-420, etc) are NOT designed to be intrinsically safe and must be installed with both physical and electrical safety barriers. Installation should only be performed by qualified individuals and companies who understand the safety requirements. Please refer to sensor installation manuals and consult local safety regulations for more information.

Discover the versatility of the MPX Series Magneto strictive Level Sensors—engineered for precision in every application

Whether you need a robust solution for harsh environments, a compact design for tight spaces, chemical resistance for corrosive settings, or flexibility for tall tank installations, the MPX Series has you covered. Choose the right sensor for your needs today and experience unparalleled accuracy and reliability
Contact Us

The MPX-F is designed with ease of use in mind. The 316 SS flexible tubing stem coils for compact shipping, and with the stem weight attached, uncoils easily into your tank, so you no longer need an 40-foot crane to install a 20-foot probe in a 20-foot tank

Float Sensor Benefits

Simple measurement principle
Provide the most reliable and accurate method of level monitoring.

Sensor Ranges

MPX float sensors are customizable for monitoring up to 32 ft with multiple float sensors.

Sensor Accuracy

Sensors are accurate within 0.05% of its detected range.

How Float Sensors Work

Magneto strictive liquid level sensors consist of a float that moves up and down a stem, or rod. The float contains a permanent magnet, and the stem houses a wire waveguide that creates a magnetic field, making it possible to detect the floats position on the stem.
An electrical pulse travels down the waveguide, magnetizing it. When the pulse meets the magnetic field from the float, a vibration, also called a strain pulse, travels back to the sensor housing.
The Float sensor or liquid level switch then measures the difference in time between the initial pulse, and the strain pulse, giving it an accurate and continuous reading of the tank’s current level.
