OPC Buffer

Matrikon OPC Buffer is a local system that collects and stores OPC data, making it accessible to any OPC Client.
Manual Datasheet
Storing process data in the field
It has now become easier to store process data either on-site or while in operation.

What Is It?

Matrikon OPC Buffer is a ready-made tool for gathering remote data, buffering it, and with the optional History-Link module, sending historical data to a central process historian. It uses an internal buffer that can be set to store specific amounts of data, overwriting older entries when full. The data is collected by an OPC Client and shared through an OPC Server with any client that needs it.

Matrikon OPC Buffer is perfect for engineers and project managers who require reliable data collection and delivery from remote locations. This adaptable system allows users to store process data either on-site or while in real-time operation. It’s a simple “store and forward” solution that transfers data from any OPC-enabled system to any historian. Unlike other remote data collection tools, it lets users view trends and analyze data directly at the source for quick troubleshooting, without needing access to the main historian. The system can be set up remotely using a wireless or Ethernet connection.

How Does It Work?
Matrikon OPC Buffer with History Link can be easily connected in sequence, creating a fast and reliable data structure with built-in redundancy. This setup is ideal for remote or isolated operational locations that aren’t connected to the main historian network.

Matrikon OPC Buffer ensures dependable remote data collection

It allows you to easily collect, store, and send historical data to a central historian. Perfect for engineers and project managers who need quick data analysis and easy integration. Start improving your data management today!
Contact Us

Matrikon OPC Buffer is a local system that gathers and stores OPC data, making it accessible to any OPC Client.

Supported OPC Specs

OPC DA (OPC Data Access) 1.0a
OPC DA (OPC Data Access) 2.0a
OPC DA (OPC Data Access) 2.05a
OPC DA (OPC Data Access) 3.0a
OPC HDA (OPC Historical Data Access) 1.00
OPC HDA (OPC Historical Data Access) 1.10
OPC HDA (OPC Historical Data Access) 1.20

Software Requirements

Microsoft Windows XP Service Pack 3 (32-bit)
Microsoft Windows XP Service Pack 2 (64-bit)
Microsoft Windows 2003 Server Service Pack 2 (32-bit and 64-bit)
Microsoft Windows 2003 Server R2 Service Pack 2 (32-bit and 64-bit)
Microsoft Windows 2008 Server Service Pack 2 (32-bit and 64-bit)
Microsoft Windows 2008 Server R2 (64-bit)
Microsoft Windows 7 Service Pack 1 (32-bit and 64-bit)
Microsoft .NET Framework 1.1

Hardware Requirements

Intel CORE2 Duo Processor
2048 MB RAM
~80 GB 7200 RPM Hard Drive

Remote Configuration

The Matrikon OPC Buffer can be set up remotely through wireless or Ethernet networks, which is especially helpful for hard-to-reach locations or sites where the weather makes it difficult to collect data manually.

Typical Applications

  • Rolling Buffer Mode: Used for performance analysis, tuning loops, short-term monitoring, and storing/transmitting data.
  • Continuous Storage Mode: Used for long-term process analysis and tracking operations.
