Thermocouple to 1-Wire AdapterType-K Thermocouple to 1-wire signal adapter for use in high-range temperature applications. Thermocouple Range: -200°C to 260°C (-328°F to 500°F) |
 |
| The X-TC1W-K is a thermocouple to 1-Wire signal adapter for use in a broad range of industrial applications. It works directly with X-400 Series, X-600M, and WebRelay Wireless modules with a 1-Wire Bus (X-410, X-420, etc.), X-600M and WebRelay-Wireless modules only. No power supply or additional software is required. Simply connect and configure using the built-in configuration and setup web pages of the host device. No additional software, or power supply required. Simply connect and set up on any of our compatible products. |
|
|
ApplicationsUse thermocouple sensors to monitor temperature in freezers, ovens, incubators, generators – Anywhere precision and rugged temperature sensors are required. |
Simplify your setup—choose the X-TC1W-K adapter today!
Compatible with the X-400 Series, X-600M, and WebRelay Wireless modules, it integrates effortlessly without the need for extra software or power supply. Just connect, configure via the host device's built-in web pages, and start monitoringStreamline your industrial temperature monitoring with the X-TC1W-K thermocouple to 1-Wire signal adapter
Features
Works with Type-K thermocouples (-200°C to 1250°C)
±0.5°C Accuracy
Built-in miniature polarized thermocouple connector
Internal cold junction temperature compensation
Fully calibrated and linearized (uses NIST Type-K thermocouple polynomial)
Digital “1-Wire®” interface
Easy to use
±0.5°C Accuracy
Built-in miniature polarized thermocouple connector
Internal cold junction temperature compensation
Fully calibrated and linearized (uses NIST Type-K thermocouple polynomial)
Digital “1-Wire®” interface
Easy to use
Compatible Products
X-400
X-400C
X-404
X-404C
X-405
X-406
X-410
X-420
X-600M
WebRelay Wireless
Advantages
Thermocouples are used extensively in the scientific and automation industries. They are available in a wide variety of industrial housings, including thermowells, threaded wells, PFA coated thermowells for corrosive applications, and high temperature lead wires. Thermocouples have a much wider range than with the “1-Wire” digital sensors (-55°C to 125°C) supported by the ControlByWeb products.
Thermocouples are workable in high temperature applications such as in a fermenter where steam is injected to sterilize the vessel.
Temperature Range: Type-K thermocouples have a measurement range of -200°C to +1250°C
Robust: Thermocouples are inexpensive, extremely simple, and rugged devices which are suitable for use in hazardous environments.
Rapid response: Because they are small and have low thermal mass, thermocouples respond rapidly to temperature fluctuations.
No self heating: Thermocouples require no excitation power; therefore, they are not prone to self heating.
Thermocouples are workable in high temperature applications such as in a fermenter where steam is injected to sterilize the vessel.
Temperature Range: Type-K thermocouples have a measurement range of -200°C to +1250°C
Robust: Thermocouples are inexpensive, extremely simple, and rugged devices which are suitable for use in hazardous environments.
Rapid response: Because they are small and have low thermal mass, thermocouples respond rapidly to temperature fluctuations.
No self heating: Thermocouples require no excitation power; therefore, they are not prone to self heating.
