VEGAPOINT 11 Capacitive Limit Switch

The VEGAPOINT 11 ultra-compact capacitive limit switch for detection of water-based liquids. Hygienic adapters available. From DK > 2, 1/2″ NPT thread, M12 connector, transistor output.

VEGAPOINT 11 Capacitive Limit Switch

The VEGAPOINT 11 ultra-compact capacitive limit switch for detection of water-based liquids. Hygienic adapters available. From DK > 2, 1/2″ NPT thread, M12 connector, transistor output.

Low-cost limit switch
For water-based liquids
Options for various media
Call for additional options

The VEGAPOINT Series of ultra-compact capacitive limit switches are your best option for liquid detection. This series can be very easily installed in a number of different applications, including the food, beverage, and pharmaceutical industries. The low-cost, low power consumption designs of the VEGAPOINT Series products provide high-end results.

Your benefit
Simple setup, as adjustment-free
Configurable to match your needs
Low-cost limit switch with smallest installation dimensions

Application Example
Storing Yeast

The yeast is grown and stored in small storage tanks at an optimal temperature, then added to the fermentation tanks as required. To ensure ideal storage, the minimum and maximum limit levels as well as the pressure in the tank are monitored.

Ensure reliable liquid detection with the VEGAPOINT 11 ultra-compact capacitive limit switch!

Ideal for water-based liquids, it’s a cost-effective solution with customizable options to suit your needs. Ready to optimize your process?

Technical data

Output signal  Transistor output PNP
Process fitting
Thread G½, G¾, G1, M24 x 1.5
Thread ½ NPT, ¾ NPT, 1 NPT
Clamp 1", 1½", 2"
Further hygienic fittings
Process pressure  -1 …25 bar (-100 … 2500 kPa/- 14.5 … 363 psig)
Process temperature  -20 … +100 °C (-4 … +212 °F)
Ambient temperature   -40 … +70 °C (-40 … +158 °F)
Operating voltage  12 … 35 V DC

Application area

The VEGAPOINT 11 is a capacitive level sensor for level detection of water-based liquids. Typical applications are overfill and dry run protection. The small sensor can also be used in thin pipelines.

Materials

The wetted parts of the instrument are made of PEEK and stainless steel 316L. The process seal is made of FKM.

Approvals

Hygienic approvals for use in the food and pharmaceutical industries are planned for the device. The technical data in the respective safety instructions are valid for approved instruments (e.g. with Ex approval). In some cases, these data can differ from the data listed herein. All approval documents can be downloaded from our homepage.
