Easy Relay Control from Anywhere
- X-WR-4R3-E,X-WR-4R3-I
Remotely control 4 electromechanical relays with the WebRelay Quad. The simple user interface and no-code logic builder makes this programmable logic controller the easiest relay control method you can find.
- 4 Relays
The WebRelay-Quad makes relay control simpler than ever. Options include using our conditional and/or scheduled logic builder with easy drop-down menus, sending commands to the device from your own software, or via industrial communication protocols like Modbus TCP/IP.
WebRelay-Quad Features
- Simple Web Dashboard
- Password Protected
- Automatic Reboot
- Remote Relay Control
WebRelay-Quad Applications
- Pump & Motor Control
- Lighting Control
- Network Device Rebooting
- Security Lock Systems
Specifications
Models
- X-WR-4R3-I
- X-WR-4R3-E
Power Requirements
- Voltage:
-
- X-WR-4R3-I: 9-28VDC
- X-WR-4R3-E (Updated): POE class 0 (0.44–12.94 Watts)
- Max Current:
-
- X-WR-4R3-I: 320mA Max
- X-WR-4R3-E: 477mA Max
Relay Contacts
- Number of Relays: 4
- Max Voltage: 28VAC, 24VDC
- Max Current: 3A
- Contact Type: SPDT (Form C)
- Load Type: General Purpose
- Contact Resistance: < 50 milliohms initial
- Contact Material: AgSnO2
- Electrical Life: 100K cycles (Typical)
- Mechanical Life: 10M cycles (Typical)
- Environmental Rating: Over voltage Category II, Pollution Degree 2
- Relay Modes: ON/OFF or Pulse
- Pulse Timer Duration: 0.1 to 86,400 Seconds (1-day)
Network
- Type: 10/100 Base-T Ethernet Port
- Setup: Static IP address assignment. TCP port selectable
Connectors
- Power & Relays 1-4: 14-Position, 3.81mm terminal spacing, Removable. For 16-28 AWG wire.
- Network: 8-pin RJ-45
LED Indicators
- Number of LEDs: 7
-
- Power on
- Relay coil energized 1-4
- Network linked
- Network activity
Physical
- Operating Temperature: -40°F to 150°F (-40°C to 65.5°C)
- Size:
-
- 1.41in (35.7mm) wide
- 3.88in (98.5mm) tall
- 3.1in (78mm) deep (not including connector)
- Weight: 5 oz (142 grams)
- Enclosure Material: Lexan 940 Polycarbonate Plastic
- Enclosure Flame Rating: UL94 V0
Protocols
- HTTP, XML, Modbus TCP/IP
Password Settings
- Password protection on setup page: Yes
- Password protection on control page: Optional
- Password Encoding: Base 64
- Password Length: 10 Characters
Electromagnetic Compliance
- IEC CISPR 22, CISPR 24
- EU EN55024, EN55022
- X-WR-4R3-I: FCC 47CFR15 (Class B)
- X-WR-4R3-E (Updated): FCC 47CFR15 (Class A)
Product Safety Compliance
- IEC 61010-1
