Remote Power Control
- XRDI-WSEP-IN,XRDI-WSEP-NA
The WebSwitch Plus™ is an IP-controlled remote power strip that’s compatible with any AC device. It features two independent power outlets that can be controlled over an IP network. The WebSwitch Plus can operate worldwide with 100-240V AC and 50/60Hz.
- 2 Relay-Controlled Power Outlets (10A)
- 2 Digital Inputs
- Up to 16 Temperature Sensors
The WebSwitch Plus is ideal for remote power control, remote reboot, and automatic reboot of network devices. Plug in a fan, heater, computer, server, camera, other network equipment—any AC device—for the ability to remotely power devices on or off. Independently control two power outlets using a standard web browser…no special software required.
WebSwitch Plus Features
- Automatic and Manual Remote Reboot
- Real-time clock, can automatically adjusts for daylight savings time, sync with NTP server
- Built-in no-code user interface for easy logic programming
- Email Notifications
- Data Logging
- Added Relay Contact Protection
- Supports up to 16 temperature sensors or up to 8 temp/humidity sensors
WebSwitch Plus Applications
- Server Room Monitoring
- Lighting Control
- IP Camera Reboot
IoT Relay with Embedded Logic
Many IoT relays require extensive programming knowledge and additional devices (PLCs, Rasberry Pi, etc.) to set up and manage. WebSwitch Plus is a stand-alone unit that comes with a built-in, no-code user interface that allows you to create custom “tasks” using intuitive drop-down menus—no additional software required. The logic is then stored on the devices and can be set up and managed using a standard web browser. Try out one of our control page demos below and see how easy it is for yourself!
Perfect for Server Room Monitoring
Automatic Reboot
The WebSwitch Plus can be set up to send ping requests to servers. If the ping request fails, WebSwitch Plus is configured to then send out another ping request after 10 seconds and if that request also fails, it will automatically reboot the server and internally log the event. It can also send out an email and text alert to an IT tech and administrator.
Monitor Server Temperature
WebSwitch Plus also monitors the server’s temperature. If the temperature exceeds a user-specified threshold, it logs the event and sends an email/text alert to the appropriate personnel.
Specifications
Power Requirements
- Voltage: 100-240V AC (47-63Hz)
- Input Frequency: 47-63Hz
- Input Connector: IEC 320 Appliance Connector (C14 Male)
- Max Current: 10A (DO NOT USE WEBSWITCH PLUS TO CONTROL MORE THAN 10 AMPS – BOTH OUTLETS)
Relay Contacts
- Number of Relays: 2
- Relay Connector: IEC C13 Female
- Contact Type: SPDT (Form C)
- Load Type: General Purpose
- Contact Resistance: < 30 milliohms initial
- Contact Material: AgSnO2
- Electrical Life: 100K cycles (Typical)
- Mechanical Life: 10M cycles (Typical)
- Environmental Rating: Over voltage Category II, Pollution Degree 2
- Relay Modes: ON/OFF or Pulse/Reboot
- Pulse Timer Duration: 0.1 to 86,400 Seconds (1-day)
Digital Inputs
- Number of Inputs: 2
- Type: Non-Isolated
- Voltage Range: 0-5VDC
- Current: 47K Pullup
- Minimum Hold Time: 20ms
- Input Isolation: Non-Isolated
- Input Functions: Emails Alerts, SNMP Traps
Temperature Sensors
- Maximum Number of Sensors: 16
- Type: Dallas Semiconductor DS18B20
- Temperature Range: -67°F to 257°F (-55°C to +125°C)
- Accuracy: ±0.5°C (from -10°C to +85°C)
- Sensor Functions: Monitor Temperature, Log Temperature, Email Alerts, SNMP Traps
Real-Time Clock
- Manual or NTP(Network Time Protocol) setup
- NTP Sync Period: Once, Daily, Weekly, On Powerup
- Auto Daylight Savings Adjustment
- Battery (capacitor) Power Backup
Capacitor Power Backup
- Backup Functions: Retain Real-Time Clock, External Variables, Outlet State.
- Backup Duration: 24 hours
Network
- Type: 10/100 Base-T Ethernet Port
- Setup: Static or DHCP IP address configuration
- Output Connectors: IEC 320 Appliance Connector (C13 Female)
- Accessory Input: 5-Position, 3.81mm
- Network: 8-pin RJ-45
LED Indicators
- Number of LEDs: 5
-
- Power on
- Out On 1-2
- Network linked
- Network activity
Physical
- Operating Temperature: -4°F to 104°F (-20°C to 40°C)
- Size:
-
- 10.65 inches (27.11 cm) wide
- 1.75 inches (4.44 cm) tall
- 3.29 inches (8.36 cm) deep
- Weight: 1 lb. 3 oz. (542 grams)
- Enclosure Material: Lexan 940 Polycarbonate Plastic
- Enclosure Flame Rating: UL94 V0
Protocols
- HTTP(S), JSON, XML, Modbus TCP/IP, SNMP, Remote Services
Logging
- Log File Size: 3072K (Max 50688 logs)
- Storage: Nonvolatile Flash
- Buffer Architecture: Circular Buffer
Password Settings
- Password protection on setup page: Yes
- Password protection on control page: Optional
- Password Encoding: Base 64
- Password Length: 6-18 Characters
Electromagnetic Compliance
- IEC CISPR 22, CISPR 24
- FCC 47CFR15
- EU EN55024, EN55022
- EN55022:2006: Class B
- EN61000-3-2
- EN61000-3-3
- EN55024:2006
- IEC 61000-4-2
- IEC 61000-4-3
- IEC 61000-4-4
- IEC 61000-4-5
- IEC 61000-4-6
- IEC 61000-4-8
- IEC 61000-4-11
- ITE-Class B
Product Safety Compliance
- CAN/CSA-C22.2 No.60950-1-03 First Edition
- IEC 61010-1
