X-13S™ | Thermocouple Expansion Module

Engineering & Marketing International

The Best Fit for Temperature Measurement

  • X-13S-K

The X-13S™ thermocouple expansion module is used with an X-400™ or X-600M™ controller. It is a 2-channel signal conditioner for Type-K thermocouples. One or more X-13S expansion modules can be connected with a ribbon cable that provides both power and communication.

  • 2 Channel Type-K Thermocouples
  • Expansion Module for the X-400 and X-600M

Thermocouples come in many shapes and sizes and apply to countless applications, including extreme temperature measurement. When connected to an X-400 or X-600M, the X-13S provides a flexible and reliable way to monitor temperature over a network. It’s suitable for use with freezers, ovens, fermenters, generators—anywhere precise, rugged temperature sensors are required.

X-13S Features

  • 2-channel thermocouple inputs
  • Type K thermocouplesRange -200°C to +1250°C
  • Two “Open Thermocouple” channel LEDs
  • Powered through expansion bus (no separate power supply connections are required)

Specifications

Power Requirements

  • Voltage: 9-28 VDC (supplied via the X-400 or X-600M controller, 24V recommended)
  • Max Current: See table below for typical values at 25°C.
Power Supply All Thermocouples Open All Thermocouples Good
9 VDC 49 mA 17 mA
12 VDC 37 mA 13 mA
24 VDC 20 mA 8 mA

Thermocouple

  • Number of channels: 2 Channels
  • Thermocouple: Type-K
  • Linear Range: -200°C to 1250°C
  • Operating Ambient: -40°C to 85°C (internal cold junction compensation)
  • Resolution: 0.027°C
  • Drift: 4ppm/°C typical, 15ppm/°C max
  • Type: Inputs are not isolated, only use ungrounded thermocouples
  • Input Current: Differential, ±165nA max
  • Error Detection Detects sensor breakage or disconnection of lead wire

Connectors

  • Type: Miniature size, Omega PCC-SMP Series, Type-K
  • Mating Connector: Miniature size, SMP
  • Expansion Connector: Ribbon cable, 10-conductor, polarized, 2×5-position, 0.100″ pitch Provides power and communications for expansion modules (Communications: RS-485)

LED Indicators

  • Number of LEDs: 3
  • Power on
  • “Open Thermocouple (Channels 1-2)

Physical

  • Size:
    • 1.41in (35.7mm) wide
    • 3.88in (98.5mm) tall
    • 3.1in (78mm) deep (not including connector)
  • Weight: 4.8 oz (136 g)
  • Enclosure Material: Lexan 940 Polycarbonate Plastic
  • Enclosure Flame Rating: UL94 V0

Environmental

  • Operating Temperature: -40°F to 150°F (-40°C to 65.5°C)
  • Storage Temperature: -40°F to 185°F (-40°C to 85°C)
  • Humidity: 5-95%, non-condensing
  • Altitude: Up to 2,000m
  • Indoor use or NEMA-4 protected location

Electromagnetic Compliance

  • IEC CISPR 22, CISPR 24
  • FCC 47CFR15 (Class B)
  • EN55024 ITE Immunity (2010)
  • EN55022 Emissions (2010)

Product Safety Compliance

  • UL 61010-1 (Electrical Equipment for Measurement, Control, and Laboratory Use)
