X-22S™ | 8 Analog Input Expansion Module

Engineering & Marketing International

Flexible Analog Monitoring

  • X-22S

 The X-22S™ eight-analog-input expansion module is used with an X-400™ or X-600M™ controller. It has eight precision analog inputs that can be configured for various voltage ranges and 4-20mA sensors.

  • 8 Analog Inputs
  • Expansion Module for the X-400™ or X-600M™

The X-22S™ is ideal for measuring precision analog voltages. This includes monitoring temperature, electrical current, pressure, and fluid levels. It is a great fit for environmental monitoring, wastewater, and greenhouse applications.

The X-22S™ employs a 16-bit SAR A/D converter and can make both single or differential input measurements. A 5.0V reference output can be used to power potentiometers or other resistance sensing sensors. One or more X-22S™ expansion modules can be connected with a ribbon cable that provides both power and communication.

X-22S™ Features

  • 8 precision analog inputs
  • Input Voltage Ranges: ±1.28V, ±2.56V, ±5.12V, ±10.24V, 4-20mA
  • Removable terminal connector
  • Powered through expansion bus (no separate power supply connections are required)
  • High input impedance

Specifications

Power Requirements

Voltage: 9-28VDC (supplied via the X-400 controller, 24V recommended)
Max Current:

Power Supply Current (voltage mode) Current (current mode)
9 VDC 42 mA 83 mA
12 VDC 32 mA 62 mA
24 VDC 17 mA 33 mA

Analog Inputs

  • Number of Inputs: 8
  • Type: Single-ended, differential, 4-20mA (0-20mA), or a combination
  • Input Range: ±1.28V, ±2.56V, ±5.12V, ±10.24V, 4-20mA
  • Resolution: 16-bit, SAR

Reference Output

  • Voltage: 5.00V
  • Accuracy: 0.04%
  • Temperature Coefficient: 3ppm/°C Max
  • Current: 25mA max

Connectors

  • Inputs: 14-Position, 3.81mm terminal spacing, Removable. For 16-28 AWG wire.
  • Expansion Connector: Ribbon cable, 10-conductor, polarized, 2×5-position, 0.100″ pitch

LED Indicators

  • Number of LEDs: 1
    • Power on

Physical

  • Size:
    • 1.41in (35.7mm) wide
    • 3.88in (98.5mm) tall
    • 3.1in (78mm) deep (not including connector)
  • Weight: 5 oz. (142 g)
  • Enclosure Material: Lexan 940 Polycarbonate Plastic
  • Enclosure Flame Rating: UL94 V0

Environmental

  • Operating Temperature: -40°C to 50°C (-40°F to 122°F)
  • Storage Temperature: -40°C to 85°C (-40°F to 185°F)
  • Humidity: 5-95%, non-condensing
  • Indoor use or NEMA-4 protected location

Electromagnetic Compliance

  • IEC CISPR 22, CISPR 24
  • FCC 47CFR15 (Class B)
  • EN55024 ITE Immunity (2010)
  • EN55022 Emissions (2010)

Product Safety Compliance

  • IEC 61010-1
