- X-408-E,X-408-I
The X-408™ is a web-enabled input module with eight optically isolated digital inputs perfect for dry contact monitoring.
- 8 Digital Inputs
- Discrete On/Off
- Counters
- Frequency
The X-408 can be used to monitor alarm panels, door sensors, flow meters, or digital pulse meters. It can be used in Peer-to-Peer (P2P) communication with other ControlByWeb modules for a wide variety of applications to increase digital inputs on your monitoring and control platform.
X-408 Features
- Email Notifications
- Customizable Web-Based Dashboard
- Peer-to-Peer Networking
- Data Logging
- 400 Series Platform
X-408 Applications
- Door & Access Control
- Alarm Panel Monitoring
- Parking Sensor Monitoring
- Digital Pulse Meter Monitoring
Specifications
Models
- X-408-I
- X-408-E
Power Requirements
- Voltage:
-
- X-408-I: 9-28 VDC
- X-408-E: POE and/or 9-28 VDC
- Max Current: 240mA
Digital Inputs
- Number of Inputs: 8
- Type: Optically-Isolated
- Voltage Range: 4-26VDC
- Current: 950uA @ 4V, 8.5mA @ 26V
- Minimum Hold Time: 20ms
- Input Functions: Monitor State, Control Relays, Control Remote Relays, Scalable Counter, On Timer, Total On Timer, Frequency
- Maximum Count: 24-bit
- Max Count Rate: 200Hz Max (Dependent on Configuration)
- Edge Trigger: Rising, Falling or Both
Real-Time Clock
- Manual or NTP(Network Time Protocol) setup
- NTP Sync Period: Once, Daily, Weekly, On Powerup
- Auto Daylight Savings Adjustment
- Battery (capacitor) Power Backup
Capacitor Power Backup
- Backup Functions: Retain Real-Time Clock, 1 Register, 2 Counters, 4 Relay States
- Backup Duration: 2 week minimum
Network
- Type: 10/100 Base-T Ethernet Port
- Setup: Static or DHCP IP address configuration
Connectors
- Power and Inputs: 14-Position, 3.81mm terminal spacing, Removable. For 16-28 AWG wire.
- Network: 8-pin RJ-45
LED Indicators
- Number of LEDs: 11
-
- Power on
- Digital Inputs 1-8
- Network linked
- Network activity
Physical
- Operating Temperature: -40°F to 150°F (-40°C to 65.5°C)
- Size:
-
- 1.41in (35.7mm) wide
- 3.88in (98.5mm) tall
- 3.1in (78mm) deep (not including connector)
- Weight: 5 oz (142 grams)
- Enclosure Material: Lexan 940 Polycarbonate Plastic
- Enclosure Flame Rating: UL94 V0
Protocols
- HTTP, HTTPS, SSL, XML, Modbus TCP/IP, SNMP, SMTP, Remote Services
Logging
- Log File Size: 512K (up to 8,448 logs)
- Storage: Nonvolatile Flash
- Buffer Architecture: Circular Buffer
Advanced Features
- Task Builder
- BASIC interpreter
- Remote services
Password Settings
- Password Length: 6-18 Characters
Electromagnetic Compliance
- IEC CISPR 22, CISPR 24
- EU EN55024, EN55022
- X-408-I: FCC 47CFR15 (Class B)
- X-408-E: FCC 47CFR15 (Class A)
Product Safety Compliance
- IEC 61010-1
