Multi-Channel Analog Output
- X-417:1-I/X-417:5-I
The X-417™ is a web-enabled analog module with up to five individually programmable outputs. Choose the number of outputs that fit your application for the most affordable analog I/O available.Note that the model numbers, labeled 1–5, correspond to the number of outputs on the PLC.
- Up to 5 Analog Outputs
- Analog Signal Mirroring
- V, mA outputs
The X-417™ is a web-enabled analog module with up to five individually programmable outputs. Choose the number of outputs that fit your application for the most affordable analog I/O available.
X-417 Features
- 1-5 Analog Outputs
- Email Notifications
- Customizable Web Dashboard
- Robust Data Logging
- 400 Series Platform
X-417 Applications
- VFD Control
- Analog Signal Mirroring
- D/A Conversion
Specifications
Power Requirements
- Voltage: 9-28VDC
- Max Current:
| Power Supply | Outputs = 0V | Outputs = 20mA |
| 9 VDC | 222 mA | 294 mA |
| 12 VDC | 166 mA | 226mA |
| 24 VDC | 93 mA | 115mA |
Analog Outputs
- Number of channels: 5 (Individually configurable)
- Output Ranges: 0-5V, 0-10V, ±5V, ±10V, 4-20mA (software selectable)
- Resolution: 16-bit DAC (0-65535)
- Linearity Error: ±1-count, monotonic DAC
- Current Output (Voltage Mode): 10mA max (min load = 1K), 30mA max short circuit
- Voltage Output Inaccuracy: ±0.2% FSR includes offset error, gain error and non-linearity error, -40 to 65°C
- Max Load Capacitance: 20nF (no load), 5nF (1K load)
- Current Output Range: 4-20mA
- Current Output Inaccuracy: ±0.2% FSR includes offset error, gain error and non-linearity error, -40 to 65°C
- Output Compliance Voltage: 11.50V min (max loop voltage)
- Isolated Power Supply: Internal DC-DC converter
- Isolation: Galvanic, 1500 VAC
- ESD Protection: Integrated 15kV protection (IEC61000-4-2)
- Output Protection: Integrated over-temperature, open-line and short circuit protection
- Output Alarms: Open current loop, high internal temperature
- Load Type: Grounded, COM of all 5-channels are connected together
- Output at power up: Programmable
Real-Time Clock
- Manual or NTP(Network Time Protocol) setup
- NTP Sync Period: Once, Daily, Weekly, On Powerup
- Auto Daylight Savings Adjustment
Capacitor Power Backup
- Backup Functions: Retain Real-Time Clock, External Variables, Relay State, and Counters
- Backup Duration: 2 week minimum
Network
- Type: 10/100 Base-T Ethernet Port
- Setup: Static IP address assignment or DHCP, HTTP port selectable
Connectors
- Power, & Outputs: 12-Position, 3.81mm terminal spacing, Removable.
- Network: 8-pin RJ-45
LED Indicators
- Number of LEDs: 8
-
- Power on
- Fault condition (channels 1-5)
- Network linked
- Network activity
Physical
- Operating Temperature: -40°F to 150°F (-40°C to 65.5°C)
- Size:
-
- 1.41in (35.7mm) wide
- 3.88in (98.5mm) tall
- 3.1in (78mm) deep (not including connector)
- Weight: 4.8 oz (136 g)
- Enclosure Material: Lexan 940 Polycarbonate Plastic
- Enclosure Flame Rating: UL94 V0
Protocols
HTTP, HTTPS, SSL, XML, SNMP, SMTP, Modbus, JSON, TCP/IP, Remote Services
Email Notifications
- Email Addresses: 8
- Encrypted Email Alerts: STARTTLS and TLSL/SSL
- Alert Functions: I/O states – Fully customizable
Logging
- Log File Size: 3072k (up to 50,688)
- Storage: Nonvolatile Flash
- Buffer Architecture: Circular Buffer
Advanced Features
Task Builer, BASIC Interpreter, Remote Services
- ControlByWeb Cloud Compatible
Password Settings
- Password protection on setup page: Yes
- Password protection on control page: Optional
- Password Encoding: Base 64
- Password Length: 13 Characters
Regulatory Compliance
- Electromagnetic Compliance:
- IEC CISPR 22, CISPR 24, EU EN55024, EN55022
- FCC 47CFR15 (Class B)
- Product Safety Compliance: IEC 61010-1
