The Ultimate Expandable I/O Solution
- X-600M-I
The X-600M™ is one of the most capable and flexible ControlByWeb PLCs. Add up to 64 expansion modules and remotely monitor and control up to 1,024 I/O. Create custom logic through the X-600M interface and run your application through a built-in web server and web browser.
- Expandable, Up to 1,024 I/O
- Relays, Analog/Digital/Thermocouple Inputs
- Up to 32 Temperature Sensors
- GUI Dashboard
The X-600M offers the most flexibility and power for the capture and use of industrial data. The modular design expands I/O solutions, and the ability to peer-to-peer network with other ControlByWeb devices extends reach in physically challenging applications.
X-600M Features
- Email Notifications
- Customizable Web-Based Dashboard
- No-Code and/or LUA Logic Programming
- Peer-to-Peer Communication
- Data Logging
X-600M Applications
- Building Automation & Access Control
- Process Control
- Remote/Field Monitoring & Control
- Dry Contact Monitoring/Notifications
Specifications
Power Requirements
- Voltage: 9-28VDC
- Max Current: See table below for typical values at 25°C,10/100Mbps.
Voltage Outputs
- Expansion Bus (X-600M-I): 1.7A max
USB
- Host: USB 2.0 Type A
- Device: USB 2.0 Mini-B
Temperature Sensors
- Maximum Number of Sensors: 32
- Type: Dallas Semiconductor DS18B20 digital 1-Wire thermometer
- Temperature Range: -67°F to 257°F (-55°C to +125°C)
- Accuracy: ±0.5°C (from -10°C to +85°C)
- Sensor Functions: Monitor Temperature, Control Expansion Module’s Relays, Control Remote Relays, Log Temperature, Email Alerts
- Humidity Type: Xytronix Model X-DTHS-WM wall mount sensor
- Humidity Range: 0-100% RH
- Accuracy: ±1.8%
Real-Time Clock
- Manual or NTP(Network Time Protocol) setup
- NTP Sync Period: Once, Daily, Weekly, On Powerup
- Auto Daylight Savings Adjustment
- Battery backup (super capacitor), 30 days min
- Accuracy ±10 seconds/month
Nonvolatile Memory
- Industrial grade eMMC NANDrive, single-level cell (SLC)
- All user settings are stored in nonvolatile memory. Settings will not be lost when power is disconnected.
Network
- 2ea 10 Base-T or 100 Base-T, 8-pin RJ-45 Ethernet connectors. Built-in 3-port L2 switch
- Setup: Static or DHCP IP address configuration
Connectors
- Power & Inputs: 5-Position, 3.81mm terminal spacing, Removable. For 16-28 AWG wire.
- Expansion Connector: Ribbon cable, 10-conductor, polarized, 2×5-position, 0.100″ pitch Provides power and communications for expansion modules (Communications: RS-485)
- Network: 8-pin RJ
LED Indicators
- Number of LEDs: 5
-
- Power on
- Network linked
- Network activity
Physical
- Operating Temperature: -40°F to 150°F (-40°C to 65.5°C)
- Size:
-
- 1.41in (35.7mm) wide
- 3.88in (98.5mm) tall
- 3.1in (78mm) deep (not including connector)
- Weight: 4.8 oz (136 g)
- Enclosure Material: Lexan 940 Polycarbonate Plastic
- Enclosure Flame Rating: UL94 V0
Protocols
- HTTP, HTTPS, SSL, SMTP, Modbus TCP/IP, Remote Services server and client
Logging
- Up to 5 log files
- Stored in Nonvolatile Flash or external USB thumb drive
- 20Mbytes max each log file (internal)
- Unlimited data storage with external USB thumb drive
- Data wraps-around when full
Password Settings
- Password protection on setup page: Yes
- Password protection on control page: Optional
- Password Encoding: Base 64
- Password Length: 20 Characters
Electromagnetic Compliance
- IEC CISPR 22, CISPR 24
- FCC 47CFR15 (Class B)
- EN55024 ITE Immunity (2010)
- EN55022 Emissions (2010)
Product Safety Compliance
- UL 61010-1 (Electrical Equipment for Measurement, Control, and Laboratory Use)
