XW-111™ | Wireless Digital Input Monitor

The XW-111™ is an easy-to-use, wireless digital input monitoring device with a built-in web server. It can sense the state of up to two switch-state closure sensors.
Manual Datasheet

XW-111 | Wireless Digital Input Monitor

The XW-111 monitors and reports the status of switch closure sensors and alarms. It’s ideal for applications where a device’s status must be monitored and Ethernet wiring is not accessible or practical to install. This could include push buttons, magnetic door alarm switches, micro-switches, or any device with a relay or switch closure output.

Two Modes of Operations

1 - Stand-Alone Mode

This mode makes the XW-111 a self-contained device that requires no additional servers or ControlByWeb devices. While in Stand-Alone mode the XW-111 can provide live, real-time input status directly to users through web browsers or the CBW Mobile app.
In addition, Stand-Alone mode offers the ability to simply monitor input status and send out email alerts (which can be converted to text message alerts) either weekly or whenever an alarm condition occurs.

In Stand-Alone mode, the XW-111:

Connects directly to Wi-Fi network - No gateway devices required
Does not require any cloud servers
Supports encrypted and un-encrypted email servers for sending temperature alerts
Allows you to customize when a email/text alert should be enabled/disabled (e.g., Disable door notifications: M-F, 8am-5pm)





2 - Slave Mode

This mode is used for measuring and reporting an input status to other ControlByWeb devices. While in Slave mode the XW-111's web interface is not directly accessible to the user, instead input status is simply transmitted to another ControlByWeb device that supports input status monitoring, such as the X-600M controller, which acts as a "master" device. The master device uses the XW-111's input status information as it would use information collected by any other input.

In Slave Mode, the XW-111:

Provides Input Information to Other ControlByWeb Devices
Acts as a wireless input for other ControlByWeb products, such as the X-600M.

Connects to Wi-Fi network
Use as wireless sensor for other ControlByWeb devices
Battery powered for limited number of transmissions or AC adapter powered for more frequent transmissions

Cost Effective

There is no special software to download, no drivers to install, and no monthly subscription. Monitoring inputs with the XW-111 is easy whether you are in the field, in the office, or on vacation. It is the ultimate solution to your wireless digital input monitoring needs!

Monitor Anywhere, Anytime!

Secure Your Devices with XW-111 – No Ethernet Needed!
Reach Us

The XW-111 can sense the state of up to two switch-closure sensors, such as: push buttons, magnetic door alarm switches, micro-switches, or any device which has a relay or switch closure output. The XW-111 can be configured for the alarm to be active when the switch is either open or closed.

Features

Wireless Wi-Fi 802.11 b/g/n
Wi-Fi transmission range up to 250ft*
Small data packets provide long battery life
Built-in web server for configuration and remote monitoring
Email/Text alerts for digital input status, and low battery alerts.
Notification scheduling - Specify when an email/text alert should be sent.
Connect a variety of switch-closure sensors
Powered by external DC power adapter or two AA batteries (battery usage for backup/low power applications only)
Each input status can control a relay on another ControlByWeb device
Supported protocols: HTTP, XML, SSL, SMTP, Remote Services
Simple and easy to use

Power Requirements

Voltage: 2AA batteries, or external 5VDC power supply
Max Current: 500ma max (via DC power wall adapter)
DC Jack: 5.5mm barrel x 2.5mm center pin (positive)

Digital Inputs

Number of Inputs: 2
Type: Non-Isolated
Voltage Range: 0-3.3VDC
Current: 200K Pullup
Minimum Hold Time: (Awake) 30mS
Minimum Hold Time: (Asleep) 100ms
Input Isolation: Non-Isolated
Input Functions: Monitor State, Trigger Email Alerts, Control Remote Relays
Edge Trigger: Rising, Falling or Both

Wireless Digital Inputs

As a standalone device, the XW-111 is a great solution in applications where hard wiring isn’t practical or convenient. Some examples include:
  • Door Open/Close
  • Window Open/Close
  • Motor On/Off
  • Water Leak Detector
  • Mechanical Switch/Push-Button
  • Loop Detector
Once connected to a network, you can access the input’s setup and control pages on a web browser where you can adjust the settings or view the current input status on the XW-111’s control page.
