ARAMCO NAOO Project

– PI System Graphics Standardization & Migration
In 2021, EMI was commissioned by ARAMCO North Area Oil Operations (NAOO) to deliver a unified and modernized PI System graphics environment. The project focused on developing a consistent design philosophy and graphic guidelines to standardize the appearance and usability of PI displays across multiple plants and fields.

EMI updated and converted legacy ProcessBook graphics into interactive PI Vision displays that featured enhanced navigation and usability.

A major effort was creating a comprehensive graphics hierarchy, allowing users to intuitively drill down from broad area overviews to detailed equipment-level screens. This hierarchy supported efficient operations and maintenance, ensuring critical information was accessible and logically organized. EMI employed a robust symbol library and naming conventions to maintain graphic consistency and ease of reference.

Extensive testing was conducted, including Factory Acceptance Testing (FAT) and Site Acceptance Testing (SAT), to ensure the graphics met ARAMCO’s high standards for performance, reliability, and user experience. The final deliverables included overview, summary, and emergency displays in both ProcessBook and PI Vision, providing flexibility during the transition period. The project successfully delivered a cohesive, professional visual environment that improved operational clarity, streamlined workflows, and enhanced user confidence across the NAOO facilities.
