Industrial UA Modbus Gateway

Secure and reliable data from remote PLC’s and devices.
Datasheet

Secure and reliable data from remote PLC’s and devices

Matrikon UA Modbus Gateway provides a simple and secure method to gain access to data from RTUs, PLCs, or any other devices that use the MODBUS data protocol. This versatile device is compact and rugged enough for use in applications where space and power are limited and wide ambient temperature swings are possible

Matrikon UA Modbus Gateway is well suited for challenging situations that include:

limited power availability in remote conditions
remote or unmanned stations that need data collection
limited space requiring a compact solution
operation in extreme temperatures and/or dusty environments
leveraging a device that does not require IT governance
minimized cost of maintenance
secure data connectivity due to company policy or regulatory requirements

Additional Options:

Din rail mounting
Ruggedized environment casing
Wireless network connectivity (coming soon)
Cellular network connectivity (coming soon)

Multiple Communication Options

Modbus RTUs come in many Modbus flavors and hardware connector types.
Matrikon UA Modbus Gateway maximizes your connectivity options with Modbus slave devise by supporting the following connection types:

RTU TCP

Serial RS232

Serial RS422

Serial RS485

Simple Installation – No Additional Training Required

Easy to setup and configure, the OPC UA Modbus Gateway can be installed by a field engineer and directly into the field. With a flexible form factor, it can be DIN Rail mounted or directly beside the RTU itself.

Secure Data Communications

Built on the inherently secure OPC UA standard; Matrikon UA Modbus Gateway provides true data security right down to the Modbus device. When installed and connected to local RTUs, OPC UA Modbus Gateway can encrypt the data as it is sent across the network. This ensures only valid, authorized, users are able to connect to and gain access to data from critical assets.



Unlock secure and easy access to your MODBUS data with the Matrikon UA Modbus Gateway

Compact and rugged, it's perfect for RTUs, PLCs, and other devices in challenging environments. Get started today for reliable data access and management!
Contact Us

UA Modbus Gateway can connect to any device that uses the standard Modbus protocol both over Serial or Ethernet connections on one side and makes it securely available to OPC UA clients on the other via OPC UA over Ethernet.

Physical Characteristics

Housing: Polycarbonate plastic
Weight: 224 g
Dimensions: 101 x 27 x 128 mm (3.98 x 1.06 x 5.04 in)
Mounting: DIN rail, wall

Environmental Limits

Operating Temperature: Standard Models: -10 to 60°C (14 to 140°F)
Storage Temperature: Standard Models: -20 to 80°C (-4 to 176°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Anti-vibration: 2 g rms @ IEC-68-2-34, random wave, 5-500 Hz, 1 hour per axis (without any USB devices attached)
Anti-shock: 20 g @ IEC-68-2-27, half sine wave, 30 ms

Power Requirements

Input Voltage: 12 to 24 VDC (3-pin terminal block, V+, V-, SG)

Certifications/Standards

Safety: UL 60950-1, EN 60950-1, CCC (GB9254, GB17625.1)
EMC: EN55022 Class B, EN 55024-4-2, EN 55024-4-3, EN 55024-4-4, FCC Part 15     Subpart B Class B
Radio: EN 301 489-1, EN 301 489-7, EN 301 511
Green Product: RoHS, CRoHS, WEEE

Reliability

Automatic Reboot Trigger: Built-in WDT (watchdog timer)

Universal Device Linking

Matrikon UA Modbus Gateway connects to third party Modbus devices regardless of what vendor they are from. With support for multiple Modbus variants, Matrikon UA Modbus Gateway easily integrates all legacy and modern Modbus data sources into the OPC UA architecture

Full Remote Management

Once Matrikon UA Modbus Gateways have been installed in the field; they can be completely managed remotely. Any configuration changes can be achieved without sending any engineers into the field
