X-418™ | 8-Channel Analog Input Module

Engineering & Marketing International

Multi-Function, 8-Channel Analog Input

  • X-418-E,X-418-I

The X-418™ is a web-enabled analog module with eight configurable analog-to-digital inputs. Perfect for sensor monitoring for tank/bin level, pressure, flow, current, and more.

  • 8 Analog Inputs (multi-function)
  • ±1.28V, ±2.56V, ±5.12V, ±10.24V
  • 4-20mA (Inputs 1-4 only)

The X-418 features an eight-channel, 16-bit, analog data acquisition system. Each channel is configurable as a single-ended or differential input. Programmable voltage ranges include; ±1.28V, ±2.56V, ±5.12V, and ±10.24V. Inputs 1-4 can be configured for 4-20mA operation. Monitor industrial sensors, pressure transducers, non-guided radar sensors, and more.

X-418 Features

  • Email Notifications
  • Customizable Web Dashboard
  • Optional BASIC Scripting
  • Robust Data Logging
  • 400 Series Platform

X-418 Applications

  • Industrial Sensor Monitoring
  • Environmental Monitoring
  • Tank Level Monitoring
  • Process Monitoring

Specifications

Models

  • X-418-I
  • X-418-E

Power Requirements

  • Voltage:
    • X-418-I: 9-28 VDC
    • X-418-E: POE and/or 9-28 VDC
  • Max Current: 152mA Max

Analog Inputs

  • Number of Inputs: 8
  • Resolution: 16-bit, SAR
  • Type: Single-ended, differential, 4-20mA (0-20mA), or a combination
  • Input Range: Inputs 1-4: ±1.28V, ±2.56V, ±5.12V, ±10.24V, 4-20mA
  • Inputs 5-8: ±1.28V, ±2.56V, ±5.12V, ±10.24V
  • Max Input Voltage (Vin): -12.5V < Vin < +12.5V
  • Input Impedance (Zin): > 500Meg Ohm
  • Channel Off Leakage: ±0.6nA (typ)
  • Input Common Mode Rejection: >100dB
  • Total Unadjusted Error: -9LSB (min), +9LSB (max)
  • Voltage Reference Drift: ±5 ppm/°C
  • Internal 4-20mA input shunt: 200-ohm, ±0.1%, 25ppm (uses ±5.12V range)
  • Logging Rate: 25 Hz

Real-Time Clock

  • Manual or NTP(Network Time Protocol) setup
  • NTP Sync Period: Once, Daily, Weekly, On Powerup
  • Auto Daylight Savings Adjustment
  • Battery (capacitor) Power Backup

Capacitor Power Backup

  • Backup Functions: Retain Real-Time Clock, 1 Register, 2 Counters
  • Backup Duration: 2 week minimum

Network

  • Type: 10/100 Base-T Ethernet Port
  • Setup: Static or DHCP IP address configuration

Connectors

  • Power and Inputs: 14-Position, 3.81mm terminal spacing, Removable. For 16-28 AWG wire.
  • Network: 8-pin RJ-45

LED Indicators

  • Number of LEDs: 3
    • Power on
    • Network linked
    • Network activity

Physical

  • Operating Temperature: -40°F to 150°F (-40°C to 65.5°C)
  • Size:
    • 1.41in (35.7mm) wide
    • 3.88in (98.5mm) tall
    • 3.1in (78mm) deep (not including connector)
  • Weight: 5 oz. (142 g)
  • Enclosure Material: Lexan 940 Polycarbonate Plastic
  • Enclosure Flame Rating: UL94 V0

Protocols

  • HTTP, HTTPS, SSL, XML, Modbus TCP/IP, SNMP, SMTP, Remote Services

Logging

  • Log File Size: 3,072K (up to 50,688 log entries depending on configuration)
  • Storage: Nonvolatile Flash
  • Buffer Architecture: Circular Buffer

Advanced Features

  • Task Builder
  • BASIC interpreter
  • Remote services

Password Settings

  • Password Length: 6-18 Characters

Regulatory Compliance

  • Electromagnetic Compliance:
    • IEC CISPR 22, CISPR 24, EU EN55024, EN55022
    • X-418-I: FCC 47CFR15 (Class B)
    • X-418-E: FCC 47CFR15 (Class A)
  • Product Safety Compliance: IEC 61010-1
