The Most Capable All-in-One I/O Solution
- X-432-I
The X-432™ is a standalone programmable PLC with 38 onboard I/O and support for local or remote monitoring and control task.
The X-432 is a powerful PLC with plenty of relays and both digital and analog inputs. It’s ideal for applications like car washes, greenhouses, lighting control, and building automation. The rugged enclosure is both wall-mountable and DIN rail-mountable (clips sold separately).
X-432 Features
- Peer-to-Peer Communication
- No-Code Logic Builder
- Customizable Web-Based Dashboard
- Data Logging
- 400 Series Platform
X-432 Applications
- Building Automation & Access Control
- Machine Control
- Elevator Control
- Water/Wastewater Treatment
Specifications
Power Requirements
- Voltage: 9-28VDC
- Max Current: 1.16A Max
Relay Contacts
- Number of Relays: 16
- Max Voltage: 30VDC, 30VAC
- Max Current: 2A
- Contact Type: SPST (Form A)
- Load Type: General Purpose
- Contact Resistance: < 100 milliohms initial
- Contact Material: AgSnO2
- Electrical Life: 100K operations (Min)
- Mechanical Life: 5M cycles (Min)
- Environmental Rating: Over voltage Category II, Pollution Degree 2
- Relay Modes: ON/OFF or Pulsed
- Pulse Timer Duration: 0.1 to 86,400 Seconds (1-day)
Optically-Isolated Digital Inputs (1-16)
- Number of Inputs: Optically-Isolated
- Voltage Range: 3-26VDC
- Current: 0.6mA @ 3V, 8.2mA @ 26V
- Minimum Hold Time: 20ms
- Input Isolation: 1500V
- Input Functions: Monitor State, Control Relays, Control Remote Relays, High Timer
- Maximum Count: 24-bit
- Max Count Rate: 200Hz Max
- Edge Trigger: Rising, Falling, or Both
General Purpose Digital Inputs (17-18)
- Number of Inputs: 2
- Number of Inputs: Non-Isolated
- Voltage Range: 0-5VDC
- Current: 47K Pull-Up
- Minimum Hold Time: 20ms
- Input Functions: Monitor State, Control Relays, Control Remote Relays, Count, High Timer
- Maximum Count: 24-bit
- Max Count Rate: 200Hz Max
- Edge Trigger: Rising, Falling, or Both
Analog Inputs
- Number of Inputs: 4
- Type: Single-ended Channels
- Input Range: 0-5 VDC
- Resolution: 12-bit
- Reference: 5.00V, 0.04%, 3ppm/C, 25mA Max
Analog Inputs
- Number of Inputs: 4
- Type: Single-ended Channels
- Input Range: 0-5 VDC
- Resolution: 12-bit
- Reference: 5.00V, 0.04%, 3ppm/C, 25mA Max
Real-Time Clock
- Manual or NTP(Network Time Protocol) setup
- NTP Sync Period: Once, Daily, Weekly, On Powerup
- Auto Daylight Savings Adjustment
- Battery (capacitor) Power Backup
Capacitor Power Backup
- Backup Functions: Retain Real-Time Clock, 1 Register, 2 Counters, 16 Relay States
- Backup Duration: 24 hours
Network
- Type: 10/100 Base-T Ethernet Port
- Setup: Static or DHCP IP address configuration
Connectors
- Power: 3-Position, 5.08mm terminal spacing, Removable. For 16-28 AWG wire.
- Relays & Inputs: 8-Position, 3.81mm terminal spacing, Removable. For 16-28 AWG wire.
- Network: 8-pin RJ-45
LED Indicators
- Number of LEDs: 35
-
- Power on
- Relay coil energized 1-16
- Optically-isolated digital inputs (1-16)
- Network linked
- Network activity
Physical
- Operating Temperature: -40℉ to 150℉ (-40℃ to 65.5℃)
- Size:
-
- 8.725in (221.6mm) wide
- 1.815in (46.1mm) tall
- 3.735in (94.9mm) deep (not including connector)
- Weight: 31.3 oz (887.3 grams) with connectors
- Material: Powder-Painted Steel
Protocols
- HTTP, HTTPS, SSL, XML, JSON, Modbus TCP/IP, SNMP, SMTP, Remote Services
Logging
- Log File Size: 3072K (Max 50688 logs)
- Storage: Nonvolatile Flash
- Buffer Architecture: Circular Buffer
Advanced Features
- Data Graphing
- BASIC interpreter
- Task Builder
Password Settings
- Password protection on setup page: Yes
- Password protection on control page: Optional
- Password Encoding: Base 64
- Password Length: 6-18 Characters
Product Safety Compliance
- IEC 61010-1
